34 m³ (44.5 yd³) - 463-9277
6060 Standard Rock Bucket
6060 Standard Rock Bucket
6060 Standard Rock Bucket
6060 Standard Rock Bucket
6060 Standard Rock Bucket
Standard Rock Loading System
34 m³ (44.5 yd³) - 463-9277
Standard Rock Bucket
Cat Standard Rock buckets are production-oriented buckets designed for use in medium-density material, which can stick to the walls of other buckets. Standard Rock buckets come equipped with wear protection for the leading edges and heel. Wear plates are usually Quenched and Tempered for maximum durability in high-impact conditions.
Material Density
3034 lb/yd³/1.8 t/m³
Wear Package
Standard Duty
Ground Engaging Tool (GET) System
Cat W950
Machine Model
6060
Specifications
Metric
|
Imperial
Material Density
3034 lb/yd³
1.8 t/m³
Wear Package
Standard Duty
Ground Engaging Tool (GET) System
Cat W950
Machine Model
6060
Capacity
44.5 yd³
34 m³
Weight
111543 lb
50595 kg
Outer Width
218.5 in
5550 mm
Inner Width
200.8 in
5100 mm
Material Density
2865 lb/yd³/1.7 t/m³
Wear Package
Extreme Duty - Abrasion
Material Density
3034 lb/yd³/1.8 t/m³
Wear Package
Extreme Duty - Impact
Material Density
3034 lb/yd³/1.8 t/m³
Wear Package
Heavy Duty - Abrasive
