735 Bare Chassis

• The 735 can be ordered with or without hoist cylinders, and in standard wheel base (SWB) or long wheel base (LWB) configurations through your local Cat dealer.

• Cat® Articulated Truck Bare Chassis are rugged and reliable platforms for water truck applications in both mining and construction projects.
• Using an articulated truck bare chassis provides a flexible solution that is ideal for dust suppression, road construction, fire protection, and other applications.
• Caterpillar works with OEMs worldwide to match various size water tanks with our bare chassis machines, all through your local Cat dealer, to provide the best solution for your business.

• Cat Articulated Truck Bare Chassis are rugged and reliable platforms for service truck applications in both mining and construction projects.
• Using an articulated truck bare chassis provides a flexible solution that is ideal for delivering fuel and preventive maintenance lubrication to your site’s machine fleet.
• Caterpillar works with OEMs worldwide to match various size service tanks with our bare chassis machines, all through your local Cat dealer, to provide the best solution for your business.

• Cat Articulated Truck Bare Chassis are rugged and reliable platforms for specialty body applications.
• Using an articulated truck bare chassis provides a flexible solution that is ideal for hauling coal or waste, container trucks or hooklifts, cable reel trucks, and other applications.
• Caterpillar works with OEMs worldwide to match various size service tanks with our bare chassis machines, all through your local Cat dealer, to provide the best solution for your business.

• Cat Articulated Truck Bare Chassis are rugged and reliable platforms for forestry applications.
• Using an articulated truck bare chassis provides a flexible solution that is ideal for hauling logs and other applications.
• Caterpillar works with OEMs worldwide to match various size service tanks with our bare chassis machines, all through your local Cat dealer, to provide the best solution for your business.

NOTE

1. Standard and optional equipment may vary. Consult your Cat dealer for details.

For more information on 735 Bare Chassis options, please contact Caterpillar OEM Solutions at [email protected].

OPERATOR ENVIRONMENT

1. Windshield wiper and washer, two speed, intermittent (front)
2. Mirrors: exterior
3. Machine operation monitoring system includes:
   – Action lamp
   – Engine oil pressure
   – Primary steering system
   – Left and right turn signal
   – High beam
   – Coolant temperature
   – Tachometer
   – Parking brake
   – Fuel level
   – Transmission oil temperature
   – Brake system
   – Transmission hold
   – Hoist control
   – Hydraulic system
   – Charging system
   – Retarder
   – Transmission fault
   – Traction control system
   – Check engine lamp
4. Storage:
   – Cup holder
   – Flask receptacle
   – Under seat storage
   – Door pocket
   – Behind operator seat storage
   – Coat hook
5. 10-inch touchscreen with Cat rearview camera
6. Seats:
   – Operator: fully adjustable, air suspension
   – Trainer: padded with lap belt
7. Retractable belt: Operator seat and second seat
8. Tilt and telescopic steering wheel
9. Sun visor
10. Liquid Crystal Display (LCD):
    – Alert indicator
    – Selected gear and direction
    – Speed or auto shift
    – Review Operation and Maintenance Manual (OMM)
    – Primary steering failure warning
    – Seat belt warning
    – Secondary steering failure warning
    – Diesel Particulate Filter (DPF) regeneration filter
    – Machine Security System (MSS) ready
    – Secondary steering energy source engaged
    – Hour meter
    – Retarder active
11. Adjustable air vents
12. Windshield wiper and washer, two speed (rear)
13. Secondary steering – electro hydraulic
14. Air conditioning with R134A refrigerant
15. Combined gear selection and hoist control lever
16. Glass windows:
    – Front, laminated and tinted
    – Sides and rear, toughened and tinted
17. Windows opening both sides, tinted
18. Heater and defroster with four-speed fan

CAT TECHNOLOGIES

1. Cat Detect with Stability Assist
2. Product Link
3. VisionLink
4. Push to Start with Operator ID
5. Product Link Cellular PLE643

ELECTRICAL AND LIGHTING

1. Horn
2. Electrical system: 24-volt, 10A 24- to 12-volt converter
3. Remote starting receptacle (cables not included)
4. Batteries (two) maintenance free
5. Main disconnect switch
6. Lighting systems:
   – Cab interior
   – Two head lamps
   – Two width marker
   – Two reversing
   – Work light/cab access light
   – Two stop/tail lights
   – Front and rear direction indicators
7. LED Rear Step Lights
8. Daylight running lights

POWERTRAIN

1. Cat C13A (LRC) or C13B (HRC) engine
2. Auto shift six-speed forward and single speed reverse transmission
3. Dual circuit oil immersed, enclosed brakes – all wheels
4. Retarder: engine compression brake
5. Differentials: standard with automatic clutched inter- and cross-axle differential locks
6. Cat Clean Emission Module (CEM) and exhaust aftertreatment package
7. Three axle, six-wheel drive
8. CX31 transmission

SAFETY

1. Rearview camera
2. ROPS/FOPS cab
3. Reverse alarm
4. Dynamic Rollover Protection
5. Machine Speed Limiting

GUARDS

1. Rear window
2. Crankcase
3. Radiator

OTHER EQUIPMENT

1. Vandalism protection: lockable caps
2. S·O·S sampling valves
3. Sound suppression (standard in some countries)
4. Mud flaps: wheel arch and body mounted with transportation tiebacks
5. Bare chassis (no body) standard wheel base

OTHER STANDARD EQUIPMENT

1. Tires, six 750/65 R25

NOTE

1. Standard and optional equipment may vary. Consult your Cat dealer for details.

OPERATOR ENVIRONMENT

1. Operator seat belt, four-point
2. Infrared glass — high ambient cab
3. Single-speed rear wiper
4. Secondary touchscreen display
5. Seat, heated/cooled
6. Mirrors, heated motorized

CAT TECHNOLOGIES

1. Cat Payload monitoring system
2. Product Link Dual PLE683
3. Operator Coaching

OPTIONAL EQUIPMENT

1. Cold weather start attachment
2. Heated/cooled seat
3. Ether start
4. Wheel chocks
5. Flashing LED beacon
6. Engine block heater
7. Sound suppression (only standard in Europe)
8. Fast fuel fill
9. Fuel additive – anti-waxing
10. Cold weather coolant –51° C (–60° F)
11. Machine Security System (MSS)
12. Product Link Elite: PLE641 (cellular). Product Link is optional.
13. Roof mounted High Intensity Discharge (HID) work lights
14. Cat Production Measurement payload monitoring system
15. Infrared glass – high ambient cab
16. Bare chassis (no body) standard wheel base
17. Exhaust heated body
18. Auto lube installation for automatic greasing of bearings
19. Bluetooth radio stereo system
20. Window blinds
21. Four-point seat belt
22. Heated rearview motorized mirrors

ELECTRICAL AND LIGHTING

1. Engine block heater
2. Ether start
3. Flashing LED beacon
4. Cold weather start attachment (2 additional batteries)
5. LED Rear Work Lights
6. Roof mounted LED work lights

SAFETY

1. Multi-view camera with object detection

OTHER EQUIPMENT

1. Fast fuel fill
2. Wheel chocks
3. Fuel additive, anti-waxing
4. Bare chassis (no body) long wheel base
5. Auto lube installation for automatic greasing of bearings
6. Cold weather coolant -51°C (-60°F)
