303.5 CR

• Choose either a canopy or a sealed and pressurized cab which can be equipped with air conditioning, adjustable wrist rests, and a suspension seat option to help keep you working comfortably all day long.

• Controls are easy to use and the intuitive Next Generation LCD monitor provides easy to read machine information. An advanced touchscreen monitor can also be equipped.

• Moving around the job site is even easier with the Cat Stick Steer option. Easily switch from traditional travel controls with levers and pedals to joystick controls to move the machine and to operate the blade. The benefit of less effort and improved control is in your hands!

• Strong lift and dig performance helps you get the job done faster. The compact radius design lets you access and work in the tightest areas. Dozer float allows for easy clean up.

• Your safety is our top priority. The Cat mini excavator is designed to help keep you safe on the job. Courtesy work lights and a fluorescent retractable seat belt are just a couple of the safety features we’ve built into the machine.

• Maintenance is quick and easy on the Cat mini excavator. Routine check points are easy to access at ground level through the side doors. The unique tilt up cab or canopy lets you reach additional service areas when needed.

• Equipped with features such as auto idle, auto engine shutdown, and efficient hydraulics with a variable displacement pump, the Cat mini excavator was designed with reducing your operating costs in mind.

• The Cat® C1.7 engine meets U.S. EPA Tier 4 Final, EU Stage V, and Japan 2014 emission standards.
• Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels up to: 20% biodiesel FAME (fatty acid methyl ester) * or 100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels. Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details.
• Auto Idle helps reduce unnecessary fuel burn and greenhouse gas emissions by allowing the engine to automatically go into idle mode when the machine is not working.
• Engine Idle Shutdown Timer reduces fuel burn, greenhouse gas emissions and unnecessary idle time by shutting down the machine after a pre-set idling period.
• Cruise control helps you maintain a constant speed as you travel across your jobsite saving fuel and reducing greenhouse gas emissions.
• The Cat® Seat Belt Reminder provides audible and visual warnings to remind operators to buckle up during machine operation. The easy-to-install system is compatible with all equipment brands to help ensure operator safety.
• Extended maintenance intervals not only reduce downtime but decrease the amount of fluid and filters that are replaced over the life of the machine.
• Remote Flash minimizes downtime and maintenance time while keeping your asset running with maximum efficiency. Alerts for machine updates are sent virtually from your Cat dealer and updates can be deployed without a dealer technician needing to be onsite.(if equipped)
• Remote Troubleshoot decreases maintenance time and keeps your machine running with maximum efficiency by allowing your Cat dealer to virtually test the machine while working. Once a problem is identified, a technician can fix it the first time, saving time and money.(if equipped)
• Cat Grade with advanced 2D and 3D technologies combine advanced guidance with optional automated machine control helping you reach grading targets while reducing fuel burn and greenhouse gas emissions by improving efficiency, job site productivity, and accuracy. (if equipped).

*Engines with no aftertreatment devices can use higher blends, up to 100% biodiesel. (for use of blends higher than 20% biodiesel, consult your Cat dealer)

ENGINE

1. Cat C1.7 NA Engine (U.S. EPA Tier 4 Final/EU Stage V)
2. Cat C1.7 NA Engine (U.S. EPA Tier 4 Final/EU Stage V)
3. Automatic Engine Idle
4. Automatic Engine Idle
5. Automatic Engine Shutdown
6. Automatic Engine Shutdown
7. Automatic Two Speed Travel
8. Automatic Two Speed Travel
9. Fuel Water Separator
10. Fuel Water Separator
11. Power on Demand (not available in all regions)
12. Power on Demand (not available in all regions)
13. Variable Displacement Piston Pump
14. Variable Displacement Piston Pump
15. Load Sensing/Flow Sharing Hydraulics
16. Load Sensing/Flow Sharing Hydraulics

HYDRAULICS

1. Smart Tech Electronic Pump
2. Accumulator
3. Smart Tech Electronic Pump
4. Automatic Swing Brake
5. Accumulator
6. Auxiliary Line Quick Disconnects
7. Automatic Swing Brake
8. One and Two Way Auxiliary Flow
9. Auxiliary Hydraulic Lines
10. Continuous Auxiliary Flow
11. One and Two Way Auxiliary Flow
12. Auxiliary Hydraulic Lines
13. Continuous Auxiliary Flow
14. Auxiliary Line Quick Disconnects

OPERATOR ENVIRONMENT

1. Tilt-up Canopy or Tilt-Up Cab
2. Stick Steer Mode
3. Tilt-up Canopy or Tilt-Up Cab
4. Travel Cruise Control
5. Top Guard ISO 10262:1998 Level I
6. Control Pattern Changer (optional in some regions)
7. ROPS – ISO 12117-2:2008
8. Adjustable Wrist Rests
9. TOPS – ISO 12117:1997
10. Washable Floor Mat
11. Travel Pedals and Hand Levers
12. Stick Steer Mode
13. Machine Security
14. Travel Cruise Control
15. Machine Security – Standard Key with Pass Code
16. Control Pattern Changer (optional in some regions)
17. Fabric Suspension Seat (Cab only)
18. Adjustable Wrist Rests
19. Vinyl Suspension Seat (Canopy only)
20. Washable Floor Mat
21. Hydraulic Lockout – All Controls
22. Travel Pedals and Hand Levers
23. Retractable High Visibility Seat Belt (75 mm/3 in)
24. Machine Security
25. Coat Hook
26. Machine Security – Standard Key with Pass Code
27. Cup Holder
28. Fabric Suspension Seat (Cab only)
29. Storage Pocket
30. Vinyl Suspension Seat (Canopy only)
31. Skylight
32. Hydraulic Lockout – All Controls
33. Mounting Bosses for Front
34. Retractable High Visibility Seat Belt (75 mm/3 in)
35. Signaling/Warning Horn
36. Coat Hook
37. Interior Light (Cab only)
38. Cup Holder
39. Boom Light, Halogen (not available in all regions)
40. Storage Pocket
41. Utility Space for Mobile Phone
42. Skylight
43. Next Generation Color LCD Monitor (IP66)
    – Fuel Level and Coolant Temperature Gauges
    – Maintenance and Machine Monitoring
    – Performance and Machine Adjustments
    – Numeric Security Code
    – Multiple Languages
    – Hour Meter with Wake Up Switch
    – Jog Dial (cab only)
44. Mounting Bosses for Front
45. Signaling/Warning Horn
46. Interior Light (Cab only)
47. Boom Light, Halogen
48. Utility Space for Mobile Phone
49. Next Generation Color LCD Monitor (IP66)
    – Fuel Level and Coolant Temperature Gauges
    – Maintenance and Machine Monitoring
    – Performance and Machine Adjustments
    – Numeric Security Code
    – Multiple Languages
    – Hour Meter with Wake Up Switch
    – Jog Dial (cab only)

    Next Generation Advanced Monitor (Optional)
    – Fuel Level and Coolant Temperature Gauges
    – Maintenance and Machine Monitoring
    – Performance and Machine Adjustments
    – Numeric Security Code
    – Multiple Languages
    – Hour Meter with Wake Up Switch

UNDERCARRIAGE

1. Rubber Belt (300 mm/11.8 in wide)
2. Dozer Blade
3. Dozer Blade Float
4. Tie Downs on Track Frame
5. Rubber Belt (300 mm/11.8 in wide)
6. Dozer Blade
7. Dozer Blade Float
8. Angle Blade
9. Tie Downs on Track Frame

BOOM, STICK AND LINKAGES

1. One Piece Boom (2400 mm/94.5 in)
2. Standard Stick (1260 mm/49.6 in)
3. Front Shovel Capable
4. Front Shovel Capable – Pin-On
5. Thumb Ready (not available in all regions)
6. Certified Lifting Eye (optional in some regions)
7. One Piece Boom (2400 mm/94.5 in)
8. Standard Stick (1260 mm/49.6 in)
9. Front Shovel Capable – Pin-On
10. Thumb Ready (not available in all regions)
11. Certified Lifting Eye (optional in some regions)

GUARDING

1. ROPS – ISO 12117-2:2008
2. TOPS – ISO 12117:1997
3. Top Guard ISO 10262:1998 (Level I)

ELECTRICAL

1. 12 Volt Battery
2. Software (machine and monitor)
3. Maintenance Free Battery
4. Lock Out/Tag Out Battery Disconnect
5. Signaling/Warning Horn
6. 12 Volt Power Socket
7. 12 Volt Battery
8. Software (machine and monitor)
9. Maintenance Free Battery
10. Signaling/Warning Horn
11. 12 Volt Power Socket

OPERATOR ENVIRONMENT

1. Cab with Air Conditioning
2. Cab with Air Conditioning
3. Cab with Heater
4. Cab with Heater
5. Control Pattern Changer (optional in some regions)
6. Control Pattern Changer (optional in some regions)
7. No Travel Pedals and Hand Levers
8. No Travel Pedals and Hand Levers
9. Machine Security – Push to Start with Key Fob/Pass Code
10. Machine Security – Push to Start with Key Fob/Pass Code
11. Vinyl Non-Suspension Seat (Canopy only)
12. Vinyl Non-Suspension Seat (Canopy only)
13. Seat Belt Reminder System
14. LED Front Lights
15. LED Front Lights
16. LED Front and Rear Lights
17. LED Front and Rear Lights
18. LED Boom Light
19. LED Boom Light
20. Mirrors Left and Right
21. Mirrors Left and Right
22. Radio – Bluetooth®, Auxiliary, Microphone, USB (charging only) (Cab only)
23. Radio – Bluetooth®, Auxiliary, Microphone, USB (charging only) (Cab only)
24. Next Generation Advanced Monitor
    – Touch Screen
    – Site Reference System
    – High Definition Camera Capable (IP68 and IP69K)
    – Numeric Security Code

UNDERCARRIAGE

1. Steel Track (300 mm/11.8 in wide)
2. Steel Track (300 mm/11.8 in wide)
3. Angle Blade

BOOM, STICK AND LINKAGES

1. Long Stick (1560 mm/61.4 in)
2. Long Stick (1560 mm/61.4 in)
3. Front Shovel Capable – Dual Lock Manual Coupler
4. Front Shovel Capable – Dual Lock Manual Coupler
5. Attachments including Couplers, Thumbs, Buckets, Augers and Hammers
6. Front Shovel Capable – Hydraulic Coupler
7. 2nd Auxiliary Hydraulic Lines
8. 2nd Auxiliary Hydraulic Lines
9. Boom Lowering Check Valve
10. Attachments including Couplers, Thumbs, Buckets, Augers and Hammers
11. Stick Lowering Check Valve
12. Boom Lowering Check Valve (Standard in Europe)
13. Hydraulic Quick Coupler Lines (not available in all regions)
14. Stick Lowering Check Valve (Standard in Europe)
15. Hydraulic Quick Coupler Lines (not available in all regions)
16. Front Shovel Capable – Hydraulic Coupler

ELECTRICAL

1. Battery Disconnect
2. Product Link PL243 (regulations apply)
3. Product Link PL243 (regulations apply)
4. Product Link PLE643 (regulations apply)
5. Product Link PLE643 (regulations apply)
6. Travel Alarm (standard in some regions)
7. Travel Alarm (standard in some regions)

GUARDING

1. Polycarbonate Half Height Front Guard (Canopy only)
2. Polycarbonate Front Guard (ISO 10262:1998 Level I and EN356 P5A)
3. Guard, Canopy
4. Guard, Mesh

OTHER

1. Bio Oil Capable
2. Eco Drain
3. Water Jacket Heater
4. Bio Oil Capable
5. Light Counterweight (100 kg/221 lb)
6. Eco Drain
7. Extra Counterweight (250 kg/551 lb)
8. Water Jacket Heater
