308 CR

• A sealed and pressurized cab is equipped with an improved air conditioning system, adjustable wrist rests and a suspension seat to help keep you working comfortably all day long.

• Controls are easy to use and the intuitive Next Generation Monitor provides customizable machine operator preferences and easy to read machine information.

• Moving around the job site is even easier with Cat Stick Steer. Easily switch from traditional travel controls with levers and pedals to joystick controls with a push of a button. The benefit of less effort and improved control is in your hands!

• Increased lifting, swinging, travel and multi-functioning performance help you get the job done more efficiently, and blade float allows for easy clean up.

• Your safety is our top priority. The Cat Mini Excavator is designed to help keep you safe on the job. A back-up camera, courtesy work lights and a fluorescent retractable seat belt are just a few of the safety features we‚Äôve built into the machine.

• Maintenance is quick and easy on the Cat Mini Excavator. Routine check points are easy to access at ground level with grouped service points and robust service panels.

• Equipped with features such as auto idle, auto engine shutdown, and efficient hydraulics with a variable displacement pump, the Cat Mini Excavator was designed with reducing your operating costs in mind.

• Your Cat dealer is here to help you reach your business goals. From providing equipment solutions to operator training to service needs and beyond, your Cat dealer is ready to help.

• The Cat® C3.3B engine meets U.S. EPA Tier 4 Final, EU Stage V, and Japan 2014 emission standards.
• Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels up to: 20% biodiesel FAME (fatty acid methyl ester) * or 100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels. Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details.
• Auto Idle helps reduce unnecessary fuel burn and greenhouse gas emissions by allowing the engine to automatically go into idle mode when the machine is not working.
• Engine Idle Shutdown Timer reduces fuel burn, greenhouse gas emissions and unnecessary idle time by shutting down the machine after a pre-set idling period.
• Cruise control helps you maintain a constant speed as you travel across your jobsite saving fuel and reducing greenhouse gas emissions.
• The Cat® Seat Belt Reminder provides audible and visual warnings to remind operators to buckle up during machine operation. The easy-to-install system is compatible with all equipment brands to help ensure operator safety.
• Extended maintenance intervals not only reduce downtime but decrease the amount of fluid and filters that are replaced over the life of the machine.
• Remote Flash minimizes downtime and maintenance time while keeping your asset running with maximum efficiency. Alerts for machine updates are sent virtually from your Cat dealer and updates can be deployed without a dealer technician needing to be onsite.(if equipped)
• Remote Troubleshoot decreases maintenance time and keeps your machine running with maximum efficiency by allowing your Cat dealer to virtually test the machine while working. Once a problem is identified, a technician can fix it the first time, saving time and money.(if equipped)
• Cat Grade with advanced 2D and 3D technologies combine advanced guidance with optional automated machine control helping you reach grading targets while reducing fuel burn and greenhouse gas emissions by improving efficiency, job site productivity, and accuracy. (if equipped).

*Engines with no aftertreatment devices can use higher blends, up to 100% biodiesel. (for use of blends higher than 20% biodiesel, consult your Cat dealer)

• Configure the machine to meet your specific application needs with a dozer straight blade or angle blade.

ENGINE

1. Cat C2.8 Turbo Diesel Engine (U.S. EPA Tier 4 Final/EU Stage V) – Electronic Engine, Turbo, Fit-For-Life Diesel Particulate Filter (DPF) and Diesel Oxidation Catalyst (DOC) Aftertreatment System
2. Cat C2.8 Turbo Diesel Engine (U.S. EPA Tier 4 Final/EU Stage V) – Electronic Engine, Turbo, Fit-For-Life Diesel Particulate Filter (DPF) and Diesel Oxidation Catalyst (DOC) Aftertreatment System
3. Automatic Engine Idle
4. Automatic Engine Idle
5. Automatic Engine Shutdown
6. Automatic Engine Shutdown
7. Automatic Swing Brake
8. Automatic Swing Brake
9. Automatic Two Speed Travel
10. Automatic Two Speed Travel
11. Fuel Water Separator with Indicator
12. Fuel Water Separator with Indicator
13. Radial Seal – Double Element Air Filter
14. Radial Seal – Double Element Air Filter
15. Extended Life Coolant, –37° C (–35° F)
16. Extended Life Coolant, –37° C (–35° F)

HYDRAULICS

1. Electronic Variable Displacement Piston Pump
2. Load Sensing/Flow Sharing Hydraulics
3. Electronic Variable Displacement Piston Pump
4. Power On Demand
5. Load Sensing/Flow Sharing Hydraulics
6. Hydraulic Temperature Monitoring
7. Power On Demand
8. Certified Accumulator
9. Hydraulic Temperature Monitoring
10. HYDO Advanced Hydraulic Oil
11. Certified Accumulator
12. HYDO Advanced Hydraulic Oil

OPERATOR ENVIRONMENT

1. Stick Steer Mode
2. Travel Cruise Control
3. Top Guard ISO 10262 1998 Level I
4. Control Pattern Changer
5. ROPS ISO 12117-2:2008
6. Adjustable Wrist Rests
7. Stick Steer Mode
8. Molded Footrests
9. Travel Cruise Control
10. Removable, Washable Floor Mat
11. Control Pattern Changer
12. Travel Pedals and Hand Levers
13. Adjustable Wrist Rests
14. Cat Key with Passcode Option
15. Molded Footrests
16. HVAC with Automatic Temperature Control
17. Removable, Washable Floor Mat
18. Hydraulic Lockout Controls
19. Travel Pedals and Hand Levers
20. Integrated Lower Front Window
21. Cat Key with Passcode Option
22. Assisted Front Window Overhead Storage
23. HVAC with Automatic Temperature Control
24. Rear Window Emergency Exit
25. Hydraulic Lockout Controls
26. Fabric, High Back, Suspension Seat
27. Integrated Lower Front Window
28. Retractable Seat Belt (75 mm/3 in)
29. Assisted Front Window Overhead Storage
30. Coat Hook
31. Rear Window Emergency Exit
32. Cup Holder
33. Fabric, High Back, Suspension Seat
34. LED Interior Light
35. Retractable Seat Belt (75 mm/3 in)
36. Literature Holder
37. Coat Hook
38. Mounting Bosses for Top and Front Guards
39. Cup Holder
40. 12V Power Socket
41. LED Interior Light
42. Radio – Bluetooth, Auxiliary, Microphone, USB (charging only)
43. Literature Holder
44. Skylight
45. Mounting Bosses for Top and Front Guards
46. Signaling/Warning Horn
47. 12V Power Socket
48. Cab and (left side) Boom Work Lights
49. Radio – Bluetooth, Auxiliary, Microphone, USB (charging only)
50. Utility Space for Mobile Phone
51. Skylight
52. Next Generation Color LCD Monitor (IP66)
    – Jog Dial Interface
    – Fuel Level and Coolant Temperature Gauges
    – Maintenance and Machine Monitoring
    – Performance and Machine Adjustments
    – Numeric Security Code
    – Multiple Languages
    – Camera Ready (IP68 & IP69K)
    – Hour Meter with Wake Up Switch
53. Signaling/Warning Horn
54. Cab and (left side) Boom Work Lights
55. Utility Space for Mobile Phone
56. Next Generation Color LCD Monitor (IP66)
    – Jog Dial Interface
    – Fuel Level and Coolant Temperature Gauges
    – Maintenance and Machine Monitoring
    – Performance and Machine Adjustments
    – Numeric Security Code
    – Multiple Languages
    – Camera Ready (IP68 & IP69K)
    – Hour Meter with Wake Up Switch

TECHNOLOGY

1. Product Link™ Elite (regulations apply)

UNDERCARRIAGE

1. Greased and Lubricated Track
2. Tie Down Eyes on Track Frame
3. Dozer Blade
4. Dozer Float
5. Greased and Lubricated Track
6. Bolt-on, Reversible Wear Edge
7. Tie Down Eyes on Track Frame
8. Dozer Blade
9. Dozer Float
10. Bolt-on, Reversible Wear Edge

BOOM, STICK AND LINKAGES

1. One Piece Boom (3400 mm/133.9 in)
2. Standard Stick (1820 mm/71.7 in)
3. Front Shovel Capable – Pin-on/Manual Coupler/Hydraulic Coupler (not available in all regions)
4. Thumb Ready (not available in all regions)
5. One Piece Boom (3400 mm/133.9 in)
6. Standard Stick (1820 mm/71.7 in)
7. Front Shovel Capable – Pin-on/Manual Coupler/Hydraulic Coupler (not available in all regions)
8. Thumb Ready (not available in all regions)

GUARDING

1. ROPS ISO 12117-2:2008
2. Top Guard ISO 10262 1998 (Level I)

ELECTRICAL

1. 12 Volt Electrical System
2. 60 Ampere Alternator
3. Circuit Breaker
4. 900 CCA Maintenance Free Battery
5. Lock Out/Tag Out Battery Disconnect
6. Ignition Key Stop Switch
7. 12 Volt Electrical System
8. Rear Camera
9. 60 Ampere Alternator
10. Circuit Breaker
11. 900 CCA Maintenance Free Battery
12. Battery Disconnect
13. Ignition Key Stop Switch

OTHER

1. Locks on External Enclosure Doors
2. Lockable Fuel Cap
3. Beacon Socket
4. Rear Reflectors
5. Locks on External Enclosure Doors
6. Lockable Fuel Cap
7. Beacon Socket
8. Rear Reflectors

OPERATOR ENVIRONMENT

1. Push to Start with Bluetooth® Key
2. Push to Start with Bluetooth® Key
3. Air Suspension Heated Seat
4. Air Suspension Heated Seat
5. Rain Visor
6. Seat Belt Reminder System
7. Next Generation Advanced Monitor (below are all included with Next Generation Advanced Monitor option)
   – Touch Screen
   – Site Reference System
   – High Definition Camera Capable (IP68 & IP69K)
   – Numeric Security Code
8. Rain Visor
9. Next Generation Advanced Monitor (below are all included with Next Generation Advanced Monitor option)
   – Touch Screen
   – Site Reference System
   – High Definition Camera Capable (IP68 & IP69K)
   – Numeric Security Code

UNDERCARRIAGE

1. Wide Dozer Blade
2. Steel Tracks (450 mm/17.7 in wide)
3. Wide Steel Tracks (600 mm/23.6 in)
4. Steel Track with Rubber Pads
5. Track Guides
6. Wide Dozer Blade
7. Dozer Angle Blade
8. Steel Tracks (450 mm/17.7 in wide)
9. Wide Steel Tracks (600 mm/23.6 in)
10. Steel Track with Rubber Pads
11. Track Guides
12. Dozer Angle Blade

BOOM, STICK AND LINKAGES

1. Long Stick (2360 mm/92.9 in)
2. Attachments including Buckets, Augers and Hammers
3. 2nd Auxiliary Hydraulic Lines
4. Boom Lowering Check Valve
5. Stick Lowering Check Valve
6. Certified Lifting Eye
7. Long Stick (2360 mm/92.9 in)
8. Attachments including Buckets, Augers and Hammers
9. 2nd Auxiliary Hydraulic Lines
10. Boom Lowering Check Valve (Standard in Europe)
11. Stick Lowering Check Valve (Standard in Europe)
12. Certified Lifting Eye

ELECTRICAL

1. Product Link™ Elite (regulations apply)
2. Travel Alarm
3. Rearview Camera
4. Rotating Beacon
5. Travel Alarm
6. Rearview Camera
7. Rotating Beacon

GUARDING

1. Mesh Front Guard ISO 10262 1998 Level I
2. Heavy Duty Front Guard ISO 10262 1998 Level II
3. Overhead Cab Guard ISO 10262 1998 Level II
4. Top Guard 10262 1998 (Level II)
5. Polycarbonate Front Window EN356 P5A
6. Front Guard (Mesh) ISO 10262 1998 (Level I)
7. Track Guards
8. Front Guard (Heavy Duty) ISO 10262 1998 (Level II)
9. Track Guards

OTHER

1. Additional Counterweight
2. Counterweight (250 kg/551 lb)
3. Water Jacket Heater
4. Counterweight (500 kg/1103 lb)
5. Refueling Pump
6. Water Jacket Heater
7. Variable Angle Boom (refer to 308 CR VAB brochure for VAB specs and additional information)
8. Refueling Pump
9. Variable Angle Boom (refer to 308 CR VAB brochure for VAB specs and additional information)

TECHNOLOGY

1. Ease of Use Indicate
2. Ease of Use E-Fence
3. Ease of Use Laser Catcher
4. Cat Grade Advanced 2D
5. Cat Grade 3D
6. Ease of Use Indicate
7. Ease of Use E-Fence
8. Cat Grade Advanced 2D
9. Cat Grade 3D
10. Product Link Elite (regulations apply)

HYDRAULICS

1. Third Auxiliary
2. Third Auxiliary
