Engine

Maximum Gross Power

60 kW

75.1 hp

82 kW

110 hp

82 kW

110 hp

Engine Model

Cat C2.8*

Cat C3.6

Maximum Engine Speed

2550 rpm

Maximum Gross Power - Rated Engine Speed

2400 r/min

1800 r/min

Maximum Gross Power - SAE J1995

60 kW

75.1 hp

Maximum Gross Power - ISO 14396

55.4 kW

74.3 hp

82 kW

110 hp

82 kW

110 hp

Maximum Gross Power - ISO 14396 (metric)

75.3 mhp

112 hp

Rated Net Power - Rated Engine Speed

2400 r/min

2200 r/min

Rated Net Power - SAE J1349

54.4 kW

73 hp

74 kW

99 hp

74 kW

99 hp

Rated Net Power - ISO 9249

53.8 kW

72.1 hp

73 kW

98 hp

73 kW

98 hp

Rated Net Power - 2,400 rpm - ISO 9249 (metric)

73.1 mhp

Maximum Gross Torque - SAE J1995

301 N·m

222 lb/ft

454 N·m

335 ft·lbf

454 N·m

335 ft·lbf

Maximum Gross Torque - ISO 14396

300 N·m

221 lb/ft

450 N·m

332 ft·lbf

450 N·m

332 ft·lbf

Maximum Net Torque - SAE J1349

296 N·m

218 lb/ft

446 N·m

329 ft·lbf

446 N·m

329 ft·lbf

Maximum Net Torque - ISO 9249

295 N·m

217 lb/ft

443 N·m

327 ft·lbf

443 N·m

327 ft·lbf

Displacement

2.8 l

171 in³

3.6 l

220 in³

3.6 l

220 in³

Bore

90 mm

3.54 in

98 mm

3.85 in

98 mm

3.85 in

Stroke

110 mm

4.33 in

120 mm

4.72 in

120 mm

4.72 in

Note

*Equivalent to U.S. EPA Tier 3 and EU Stage IIIA.

Net power advertised is the power available at the flywheel plus front drive implement pump when the engine is equipped with fan, air cleaner, muffler and alternator.

Note (1)

Maximum gross and net torque measured at 1,600 rpm.

Note (2)

Net power ratings are tested at the reference conditions for the specified standard.

Note (3)

Net power advertised is the power available at the flywheel.

Emissions

Engine meets Tier 4 Final/Stage V emission standards.

Weights

Operating Weight

6632 kg

14617 lb

8109 kg

18102 lb

8668 kg

19103 lb

Buckets

Bucket Capacities

0.75-1.55 m³ (1.0-2.0 yd³)

1.3-3.5 m3 (1.7-4.6 yd3)

Bucket Capacities - General Purpose

0.80-1.35 m³ (1.0-1.7 yd³)

1.3-1.9 m³ (1.7-2.5 yd³)

Bucket Capacities - Light Material

1.25-1.55 m³ (1.6-2.0 yd³)

2.5-3.5 m³ (3.3-4.6 yd³)

Multi-Purpose

0.75-1.1 m³ (1.0-1.4 yd³)

Note

All capacities are applicable for each model. Bucket selection must be made with an understanding of the material density and application to ensure machine stability is maintained within the tipping loads stated per model and configuration.

Note (1)

Bucket capacities stated include BOCE, in line with ISO 7546.

Service Refill Capacities

Fuel Tank

90 l

24 Gal

165 l

43.6 gal (US)

165 l

43.6 gal (US)

Cooling System

12 l

3.2 Gal

21.5 l

5.7 gal (US)

21.5 l

5.7 gal (US)

Engine Crankcase

8.8 l

2.3 Gal

10 l

2.6 gal (US)

10 l

2.6 gal (US)

Axles - Front Center Differential

8.8 l

2.3 Gal

7.5 l

2 gal (US)

7.5 l

2 gal (US)

Axles - Rear Center Differential

8.8 l

2.3 Gal

7.5 l

2 gal (US)

7.5 l

2 gal (US)

Hydraulic System - Including Tank

70.5 l

18.6 Gal

98 l

25.9 gal (US)

98 l

25.9 gal (US)

Hydraulic Tank

44.6 l

11.8 Gal

55 l

14.5 gal (US)

55 l

14.5 gal (US)

Transmission

2.4 l

0.6 Gal

3.2 l

0.8 gal (US)

3.2 l

0.8 gal (US)

Note

No Diesel Exhaust Fluid (DEF) fluid needed on this size engine.

DEF used in Cat SCR systems must meet the requirements outlined in the International Organization for Standardization (ISO) standard 22241-1.

Diesel Exhaust Fluid (DEF) Tank

18 l

4.8 gal (US)

18 l

4.8 gal (US)

Axles

Front

Fixed (standard)

Fixed; Locking differential (standard)

Rear

Fixed (standard)

Oscillating ±11 degrees; Locking differential (Standard)

Note

Oscillation of ±11 degrees via hitch between front and rear frames.

Steering

Steering Articulation Angle - Each Direction

39 °

40 °

Maximum Flow - Steering Pump

46.7 l/min

12.3 gal/min

66 l/min

17 gal/min

82 l/min

22 gal/min

Maximum Working Pressure - Steering Pump

23000 kPa

3336 psi

18500 kPa

2683 psi

22500 kPa

3263 psi

Steering Cycle Times – (full left to full right) – at High Idle

2.8 s

Number of Steering Wheel Turns - Full Left to Full Right or Full Right to Full Left

3.25 turns or 4.00 turns

3.75 turns

Steering Cycle Times - Full Left to Full Right - At 2,350 rpm: 90 rpm Steering Wheel Speed

3.2 s

2.8 s

Transmission

Forward and Reverse - Speed Range Creep#

10 km/h

6 mile/h

Forward and Reverse - Speed Range 1*

10 km/h

6 mile/h

10 km/h

6.3 mile/h

10 km/h

6.3 mile/h

Forward and Reverse - Speed Range 2** - High Speed

18 km/h

11 mile/h

Forward and Reverse - Speed Range 2** - Standard

20 km/h

12 mile/h

Forward and Reverse - Speed Range 3***

40 km/h

25 mile/h

Note

#Factory default shown, can be adjusted to any speed up to 19 km/h (12 mph).

*Creeper Control allows speed control from a stand still up to 10 km/h (6.3 mph). The Creeper Control will only work in Range 1.

Note (1)

*Creep function not available in this gear or above.

Note (2)

**Max speed dependent on model and configuration (standard vs. high speed transmission).

Note (3)

***Reverse is 30 km/h (19 mph).

Forward and Reverse - Speed Range 3

40 km/h

25 mile/h

40 km/h

25 mile/h

Forward and Reverse - Speed Range 2*

20 km/h

12.5 mile/h

20 km/h

12.5 mile/h

Tires

Tire Size - Standard

*405/70 R20 SPT9

Tire Size - Optional

405/70 R20 Powerloads

Tire Size - Optional (1)

400/70 R20 XMCL/Bibload

Tire Size - Optional (2)

360/80 R20 TRI 2

Tire Size - Optional (3)

40X14-20 TL, SM/TR

Note

*This tire has been used for all dimension, stability and performance data.

Note (1)

Other tire choices are available. Contact your Cat dealer for details.

Note (2)

In certain applications, the loader’s productive capabilities may exceed the tire’s tonnes-km/h (ton-mph) capabilities.

Note (3)

Caterpillar recommends that you consult a tire supplier to evaluate all conditions before selecting a tire model.

Standard Size

15.5 R25 L2 XTLA

17.5 R25 L2 XTLA

Other Choices Include

17.5 R25 L2 XTLA; 15.5 R25 L3 XHA2; 17.5 R25 L3 XHA2; 17.5-25 L2/L3 SGL; 17.5-25 L3 HRL D/L-3A; 17.5 R25 L2 Snow

17.5 R25 L3 XHA2; 17.5-25 L2/L3 SGL; 17.5-25 L3 HRL D/L-3A; 17.5 R25 L2 Snow; 17.5 R25 Solid

Cab

ROPS

ISO 3471:2008

FOPS

ISO 3449:2005 Level II

ISO 3449:2005

Note (1)

Canopy and cab, Rollover Protective Structures (ROPS) are available worldwide. Canopy not available in EU.

Cab and Rollover Protective Structures (ROPS) are standard in North America and Europe.

Note (2)

The declared dynamic operator sound pressure levels per ISO 6396:2008*, when properly installed and maintained, is 71 dB(A).

The declared dynamic operator sound pressure levels per ISO 6396:2008*, when the cab is properly installed and maintained, is 77 dB(A).

Note (3)

*Measurements were conducted with the cab doors and windows closed.

The labelled sound power level for the CE marked configurations when measured according to the test procedure and conditions specified in 2000/14/EC (as amended by 2005/88/EC) is 103 dB(A).

Note (4)

The labelled sound power level for the CE marked configurations when measured according to the test procedure and conditions specified in 2000/14/EC is 101 dB(A). 99 dB(A) Low Sound – Option available.

*The measurements were conducted with the cab doors and windows closed.

Loader Hydraulic System

Main Relief - 1st Auxiliary (3rd slice)

23500 kPa

3408 psi

Main Relief - 1st Auxiliary (3rd slice) - Standard Flow*

90 l/min

24 gal/min

Main Relief - 1st Auxiliary (3rd slice) - High Flow*

125 l/min

33 gal/min

Main Relief - 2nd Auxiliary (4th slice)

23500 kPa

3408 psi

Main Relief - 2nd Auxiliary (4th slice) - Flow

45 l/min

12 gal/min

Hydraulic Cycle Time - Rackback

2.5 s

2.2 s

Hydraulic Cycle Time - Lift

5.8 s

Hydraulic Cycle Time - Dump

1.8 s

Hydraulic Cycle Time - Float Down

3.6 s

Note

* Maximum flow stated, actual flow delta could be 6% from data shown. Also adjustable from 20% to 100% of maximum flow through display.

Hydraulic Cycle Time - Dump, at Maximum Reach

1.4 s

Hydraulic Cycle Time - Total Cycle Time

12.5 s

Maximum Working Pressure - Implement Pump

23500 kPa

3408 psi

28000 kPa

4061 psi

Relief Pressure - Tilt Cylinder

34000 kPa

4931 psi

34000 kPa

4931 psi

Relief Pressure - Tilt Cylinder - 3rd Function Maximum Working Pressure

21000 kPa

3046 psi

21000 kPa

3046 psi

Hydraulic Cycle Time - Raise, Ground Level to Maximum Lift

5.2 s

Maximum Flow - Implement Pump

122 l/min

32 gal/min

148 l/min

39 gal/min

Relief Pressure - Tilt Cylinder - 4th Function Maximum Working Pressure

21000 kPa

3046 psi

21000 kPa

3046 psi

Maximum Flow - Implement Pump - 4th Function, Maximum Flow

90 l/min

24 gal/min

90 l/min

24 gal/min

Maximum Flow - Implement Pump - 3rd Function, Maximum Flow

90 l/min

24 gal/min

Hydraulic Cycle Time - Float Down, Maximum Lift to Ground Level

3.7 s

Maximum Flow - Implement Pump - 3rd Function, Maximum Flow, Standard

90 l/min

24 gal/min

Maximum Flow - Implement Pump - 3rd Function, Maximum Flow, High

120 l/min

32 gal/min

Dimensions - With HPL-V Coupler - Approximate#

Height: Ground to Cab**

2670 mm

8.75 ft

Height: Ground to Beacon**

2853 mm

9.33 ft

Height: Ground Axle Center**

519 mm

1.67 ft

Height: Ground Clearance**

320 mm

1 ft

Length: Overall*

5549 mm

18.17 ft

Length: Rear Axle to Bumper

1391 mm

4.5 ft

Length: Hitch to Front Axle

1085 mm

3.5 ft

Length: Wheel Base

2170 mm

7.08 ft

Clearance: Bucket at 45° *

2615 mm

8.5 ft

Clearance: Load over Height**

2957 mm

9.67 ft

Clearance: Level Bucket**

3197 mm

10.42 ft

Height: Bucket Pin**

3404 mm

11.08 ft

Height: Overall**

4304 mm

14.08 ft

Reach: Bucket at 45° *

770 mm

2.5 ft

Carry Height: Bucket Pin

353 mm

1.08 ft

Dig Depth**

109 mm

0.42 ft

Width: Bucket

2080 mm

6.75 ft

Width: Tread Center

1570 mm

5.08 ft

Turning Radius: Over Bucket

4570 mm

14.92 ft

Width: Over Tires

1990 mm

6.5 ft

Turning Radius: Outside of Tires

4087 mm

13.33 ft

Turning Radius: Inside of Tires

2033 mm

6.67 ft

Rack Angle at Full Lift

53°

Dump Angle at Full Lift

45°

Rack Angle at Carry

51°

Departure Angle - Degrees

30°

Articulation Angle - Degrees

39°

Operating Weight: Bucket ^

6632 kg

14617 lb

Tipping Load - Straight - ISO 14397-1 †

4812 kg

10604 lb

Tipping Load - Full Turn - ISO 14397-1 †

4060 kg

8947 lb

Operating Weight: Carriage and Tines ^^

6467 kg

14252 lb

Tipping Load - Straight †

3920 kg

8639 lb

80% of Tip: Firm and Level EN474-3 ††

2638 kg

5813 lb

Note (1)

*Vary with bucket

Note (2)

**Vary with tire

Note (3)

^Horizontal Pin Lock Coupler (HPL-V) or Vertical Pin Coupler (SSL), 1.15 m3 (1.5 yd3) general purpose bucket.

Note (4)

^^Horizontal Pin Lock Coupler (HPL-V) or Vertical Pin Coupler (SSL), class III carriage, 1220 mm (4 ft) tines (500 mm [20 in] load center).

Note (5)

†Full compliance to ISO 14397-1 (2007) Sections 1 thru 6 (fork 500 mm [20 in] load center), which requires 2% verification between calculation and testing.

Note (6)

††Full compliance to EN474-3 and SAE J1197.

Note (7)

#HPL-A weight, tipping and rated loads are within 1% of the HPL-V.

Note (8)

Dimensions listed are for a machine configured with standard cab, heater, 20 km/h (12 mph), standard guarding, 80 kg (176 lb) operator, full fluids, SPT9 405/70 R20 tires and 1.15 m3 (1.5 yd3) general purpose bucket with bolt-on cutting edge or a class III fork carriage and tines, (tire supplier variability can impact dimensions by 2%).

Dimensions - With SSL Coupler - Approximate

Height - Ground to Cab

2670 mm

8.75 ft

Height: Ground to Beacon**

2853 mm

9.33 ft

Height: Ground Axle Center**

519 mm

1.67 ft

Height - Ground Clearance

320 mm

1 ft

Length - Overall with Bucket

5707 mm

18.67 ft

Length: Rear Axle to Bumper

1391 mm

4.5 ft

Length: Hitch to Front Axle

1085 mm

3.5 ft

Length - Wheel Base

2170 mm

7.08 ft

Clearance - Bucket at 45°

2502 mm

8.17 ft

Clearance: Load over Height**

2957 mm

9.67 ft

Clearance - Level Bucket

3189 mm

10.42 ft

Height - Bucket Pin

3404 mm

11.08 ft

Height: Overall**

4395 mm

14.42 ft

Reach - Bucket at 45°

872 mm

2.83 ft

Carry Height: Bucket Pin

374 mm

1.17 ft

Dig Depth

117 mm

0.45 ft

Width - Bucket

2080 mm

6.75 ft

Width - Tread Center

1570 mm

5.08 ft

Turning Radius - Over Bucket

4613 mm

15.08 ft

Width - Over Tires

1990 mm

6.5 ft

Turning Radius: Outside of Tires

4087 mm

13.33 ft

Turning Radius - Inside Tire

2033 mm

6.67 ft

Rack Angle at Full Lift

49°

Dump Angle at Full Lift

45°

Rack Angle at Carry

53°

Departure Angle - Degrees

30°

Articulation Angle - Degrees

39°

Operating Weight: Bucket ^

6718 kg

14806 lb

Tipping Load – Straight – ISO 14397-1 †

4347 kg

9581 lb

Tipping Load – Full Turn – ISO 14397-1 †

3623 kg

7985 lb

Operating Weight: Carriage and Tines ^^

6530 kg

14391 lb

Tipping Load - Straight †

3649 kg

8043 lb

80% of Tip: Firm and Level EN474-3 ††

2468 kg

5438 lb

Note (1)

*Vary with bucket

Note (2)

**Vary with tire

Note (3)

^Horizontal Pin Lock Coupler (HPL-V) or Vertical Pin Coupler (SSL), 1.15 m3 (1.5 yd3) general purpose bucket.

Note (4)

^^Horizontal Pin Lock Coupler (HPL-V) or Vertical Pin Coupler (SSL), class III carriage, 1220 mm (4 ft) tines (500 mm [20 in] load center).

Note (5)

†Full compliance to ISO 14397-1 (2007) Sections 1 thru 6 (fork 500 mm [20 in] load center), which requires 2% verification between calculation and testing.

Note (6)

††Full compliance to EN474-3 and SAE J1197.

Note (7)

#HPL-A weight, tipping and rated loads are within 1% of the HPL-V.

Note (8)

Dimensions - High Lift - With HPL-V Coupler - Approximate#

Height: Ground to Cab**

2670 mm

8.75 ft

Height: Ground to Beacon**

2853 mm

9.33 ft

Height: Ground Axle Center**

519 mm

1.67 ft

Height: Ground Clearance**

320 mm

1 ft

Length: Overall*

6163 mm

20.17 ft

Length: Rear Axle to Bumper

1391 mm

4.5 ft

Length: Hitch to Front Axle

1085 mm

3.5 ft

Length: Wheel Base

2170 mm

7.08 ft

Clearance: Bucket at 45° *

3294 mm

10.75 ft

Clearance: Load over Height**

4238 mm

14.08 ft

Clearance: Level Bucket**

3682 mm

12 ft

Height: Bucket Pin**

3889 mm

12.75 ft

Height: Overall**

4789 mm

15.67 ft

Reach: Bucket at 45° *

1042 mm

3.42 ft

Carry Height: Bucket Pin

508 mm

1.67 ft

Dig Depth**

109 mm

0.33 ft

Width: Bucket

2080 mm

6.75 ft

Width: Tread Center

1570 mm

5.08 ft

Turning Radius: Over Bucket

4869 mm

15.92 ft

Width: Over Tires

1990 mm

6.5 ft

Turning Radius: Outside of Tires

4087 mm

13.33 ft

Turning Radius: Inside of Tires

2033 mm

6.67 ft

Rack Angle at Full Lift

70°

Dump Angle at Full Lift

40°

Rack Angle at Carry

47°

Departure Angle - Degrees

30°

Articulation Angle - Degrees

39°

Operating Weight: Bucket ^

6762 kg

14902 lb

Tipping Load - Straight - ISO 14397-1 †

4113 kg

9064 lb

Tipping Load - Full Turn - ISO 14397-1 †

3446 kg

7595 lb

Operating Weight: Carriage and Tines ^^

6771 kg

14923 lb

Tipping Load - Straight †

3194 kg

7039 lb

80% of Tip: Firm and Level EN474-3 ††

2152 kg

4743 lb

Note (1)

*Vary with bucket

Note (2)

**Vary with tire

Note (3)

^Horizontal Pin Lock Coupler (HPL-V) or Vertical Pin Coupler (SSL), 1.15 m3 (1.5 yd3) general purpose bucket.

Note (4)

^^Horizontal Pin Lock Coupler (HPL-V) or Vertical Pin Coupler (SSL), class III carriage, 1220 mm (4 ft) tines (500 mm [20 in] load center).

Note (5)

†Full compliance to ISO 14397-1 (2007) Sections 1 thru 6 (fork 500 mm [20 in] load center), which requires 2% verification between calculation and testing.

Note (6)

††Full compliance to EN474-3 and SAE J1197.

Note (7)

#HPL-A weight, tipping and rated loads are within 1% of the HPL-V.

Note (8)

Dimensions - High Lift - With SSL Coupler - Approximate

Height: Ground to Cab**

2670 mm

8.75 ft

Height: Ground to Beacon**

2853 mm

9.33 ft

Height: Ground Axle Center**

519 mm

1.67 ft

Height: Ground Clearance**

320 mm

1 ft

Length: Overall*

6319 mm

20.67 ft

Length: Rear Axle to Bumper

1391 mm

4.5 ft

Length: Hitch to Front Axle

1085 mm

3.5 ft

Length: Wheel Base

2170 mm

7.08 ft

Clearance: Bucket at 45° *

3131 mm

10.25 ft

Clearance: Load over Height**

4238 mm

14.08 ft

Clearance: Level Bucket**

3675 mm

12 ft

Height: Bucket Pin**

3889 mm

12.75 ft

Height: Overall**

4880 mm

16 ft

Reach: Bucket at 45° *

1098 mm

3.58 ft

Carry Height: Bucket Pin

529 mm

1.67 ft

Dig Depth**

80 mm

0.25 ft

Width: Bucket

2080 mm

6.75 ft

Width: Tread Center

1570 mm

5.08 ft

Turning Radius: Over Bucket

4912 mm

16.08 ft

Width: Over Tires

1990 mm

6.5 ft

Turning Radius: Outside of Tires

4087 mm

13.33 ft

Turning Radius: Inside of Tires

2033 mm

6.67 ft

Rack Angle at Full Lift

66°

Dump Angle at Full Lift

33°

Rack Angle at Carry

41°

Departure Angle - Degrees

30°

Articulation Angle - Degrees

39°

Operating Weight: Bucket ^

6862 kg

15124 lb

Tipping Load - Straight - ISO 14397-1 †

3749 kg

8262 lb

Tipping Load - Full Turn - ISO 14397-1 †

3126 kg

6888 lb

Operating Weight: Carriage and Tines ^^

6834 kg

15062 lb

Tipping Load - Straight †

2923 kg

6442 lb

80% of Tip: Firm and Level EN474-3 ††

1982 kg

4368 lb

Note (1)

*Vary with bucket

Note (2)

**Vary with tire

Note (3)

^Horizontal Pin Lock Coupler (HPL-V) or Vertical Pin Coupler (SSL), 1.15 m3 (1.5 yd3) general purpose bucket.

Note (4)

^^Horizontal Pin Lock Coupler (HPL-V) or Vertical Pin Coupler (SSL), class III carriage, 1220 mm (4 ft) tines (500 mm [20 in] load center).

Note (5)

†Full compliance to ISO 14397-1 (2007) Sections 1 thru 6 (fork 500 mm [20 in] load center), which requires 2% verification between calculation and testing.

Note (6)

††Full compliance to EN474-3 and SAE J1197.

Note (7)

#HPL-A weight, tipping and rated loads are within 1% of the HPL-V.

Note (8)

Sustainability

Recyclability

95%

1300 881 064

Wheel Loaders

Compare Models

Wheel Loaders

Compare Models

Engine

Weights

Buckets

Service Refill Capacities

Axles

Steering

Transmission

Tires

Cab

Loader Hydraulic System

Dimensions - With HPL-V Coupler - Approximate#

Dimensions - With SSL Coupler - Approximate

Dimensions - High Lift - With HPL-V Coupler - Approximate#

Dimensions - High Lift - With SSL Coupler - Approximate

Sustainability
